Model

Frequency, MHz

Power Rating, watts CW

Power Rating, watts SSB

Power Rating, AM/FM

Power Rating, RTTY/AMTOR

VSWR at frequency

Forward Gain, dBd / Elements on 10 m

Forward Gain, dBd / Elements on 15 m

Forward Gain, dBd / Elements on 20 m

Front-to-Back Ratio, dB 10 m

Front-to-Back Ratio, dB 15 m

Front-to-Back Ratio, dB 20 m

Maximum Element Length

Turning Radius

Mast Mount hardware (equipped)

Assembled Weight

Wind Surface Area

Wind Load, EIA Standard 80 MPH

Warranty

Recommended Coax

Automatic band switching by means of high-impedance resonant trap circuits.

Mosley rotatable Dipoles are the perfect answer for those limited with space, but want the flexibilty to expand down the road. All rotatable dipoles listed below can be expanded to beams down the road with conversion kits.

As with all Mosley antennas, pieces are all pre-drilled and color coded, which makes assembly quick and easy. Our hardware is made of the best grade of stainless steel and our tubing is aircraft grade drawn aluminum. The warranty is two year against any defects of material or workmanship.

For MONO-BAND Rotatable Dipoles CLICK HERE!

Multi-Band Rotatable Dipoles

Mosley reserves the right to change product and material specifications without prior notice or obligation.

MINI-31-A

28, 21, 14

500

1000

250

1.0/1 to 2.0/1

0 / 1

17.0625 ft / 5.2 m

8.53 ft / 2.6 m

1.5 in / 3.81 cm

2.5 lbs / 1.13 kg

0.8 sq ft / 0.07 sq m

28 lbs / 12.7 kg

2 years

RG-8 / RG-213

MINI-21-A

24, 18

500

1000

250

1.0/1 to 2.0/1

0 / 1

17.0625 ft / 5.2 m

8.53 ft / 2.6 m

1.5 in / 3.81 cm

2.5 lbs / 1.13 kg

0.8 sq ft / 0.07 sq m

28 lbs / 12.7 kg

2 years

RG-8 / RG-213

TA-31-JR-N

28, 21, 14

500

1200

250

1.0/1 to 1.6/1

0 / 1

23.92 ft / 7.29 m

12 ft / 3.66 m

1.5 in / 3.81 cm

9 lbs / 4.08 kg

0.8 sq ft / 0.074 sq m

25 lbs / 11.34 kg

2 years

RG-8 / RG-213

TW-21-M

24, 18

1500

2500

600

1.0/1 to 1.5/1

0 / 1

23.92 ft / 7.29 m

12 ft / 3.66 m

1.5 in / 3.81 cm

11 lbs / 4.99 kg

1.2 sq ft / 0.111 sq m

40 lbs / 18.14 kg

2 years

RG-8 / RG-213

Model

Frequency, MHz

Power Rating, watts CW

Power Rating, watts SSB

Power Rating, AM/FM

Power Rating, RTTY/AMTOR

VSWR at frequency

Forward Gain, dBd / Elements on 12 m

Forward Gain, dBd / Elements on 17 m

Forward Gain, dBd / Elements on 30 m

Front-to-Back Ratio, dB 12 m

Front-to-Back Ratio, dB 17 m

Front-to-Back Ratio, dB 30 m

Maximum Element Length

Turning Radius

Mast Mount hardware (equipped)

Assembled Weight

Wind Surface Area

Wind Load, EIA Standard 80 MPH

Warranty

Recommended Coax

TA-31-M

28, 21, 14

1500

2500

600

1.0/1 to 1.5/1

0 / 1

23.92 ft / 7.29 m

12 ft / 3.66 m

1.5 in / 3.81 cm

11 lbs / 4.99 kg

1.2 sq ft / 0.111 sq m

40 lbs / 18.14 kg

2 years

RG-8 / RG-213

TW-31-XL

24, 18, 10

1500

2500

600

1.0/1 to 1.5/1

0 / 1

29.58 ft / 9.02 m

16 ft / 4.88 m

2 in / 5.08 cm

20 lbs / 9.07 kg

1.8 sq ft / 0.167 sq m

48 lbs / 21.77 kg

2 years

RG-8 / RG-213

Trapped Wire Dipoles & Wire Antennas

ITEM

DESCRIPTION

SPEC SHEET

ANT-DIV-80

ANT-MD-2

ANT-MD-3-JR

ANT-MD-5

ANT-MD-6

Click on the model number link to see specifications or contact us for details.

ANT-DIV-80

ANT-MD-2

ANT-MD-3-JR

ANT-MD-5

ANT-MD-6

Dipole or inverted 'V' antenna DIY wire antenna kit

Trap Master MD-TD trapped wire dipole, 40-80 meter

Trap Master MD-TD low power, trapped wire dipole, 10-15-20 or 40 meter

Trap Master MD-TD trapped wire dipole, 10-15-20 or 40 meter

Trap Master MD-TD trapped wire dipole, 10-15-20-40-75/80 meter

Trap Master MD-TD trapped wire dipole, 10-12-15-17-20-40

Dipole Antenna Designs

Automatic band switching by means of high-impedance resonant trap circuits.
